  Description

  The fail-safe Ex-Temperature Controller devices of the IR2M-Series are mechanical 2-point capillary temperature controller. The black glass-fibre-reinforced polyester enclosure as well as the stainless steel enclosure (both ATEX/IECEX and NEMA 4X approved) is very rugged and is used as a connector for single core heating cables as well as self-limiting heating cables. This controller can handle a switching capacity up to 16A directly. When exceeding the adjusted temperature, the controller switches off.

  Technical data IR2M_EX

  • Min. ambient temperature: -40°C (-55°C on request)
  • Switching capacity NC: 25A/230V (16A/400V on request)
  • Temperature class: T6 at +50°C
  • Temperature range: -20…+50°C/ 0...120°C/0...+190°C/60…+300°C/ 140...500°C;
  • Other temperature range on request
  • also available as double thermostat IRR2MEx (s. operation manual)
